PURPOSE OF MACHINE
- The DOCTOR-300FB (D3) model operates in forward & backward directions to return roll to defect position. The machine operates at 400 meters / min. It is ideal for inspection of narrow web labels and low tension with high speed.
FEATURES
- Cantilevered unwind and rewind
- High speed roll doctoring with precision
- Auto. reverse function
- Unwind and rewind edge guides
- Closed loop tension control
- Pneumatic lay-on rollers
Model |
DOCTOR-300FB |
Speed(M/min) |
400 |
Web width(mm) |
300 |
Min. Web width(mm) |
30 |
Unwind diameter(mm) |
600 |
Rewind diameter(mm) |
600 |
