Máquina automática de soplado FS-40PDDL-75

Máquina automática de soplado FS-40PDDL-75
AUTOMATIC CO -EXTRUSION
Clasificación: Máquina automática de moldeo por soplado
FULL SHINE PLASTIC MACHINERY CO., LTD.
FULL SHINE PLASTIC MACHINERY CO., LTD.
País: Taiwán
Teléfono: 886-4-22765071
Fax: 886-4-22765070
Persona de contacto: Ms. Huang
Consulta Ahora

<•CO-EXTRUSION BLOW MOLDING MACHINE FOR MULTI-LAYER BOTTLES – Applicable for single and double station with single to multiple die heads for producing up to SIX-LAYER CONTAINERS (2 TO 6-LAYER CO-EXTRUSION), such as chemical bottles, catchup bottles, or cosmetic bottles. >
• La aplicación de coextrusión permite que los materiales no relacionados con diferentes características se combinen en un parison a través del cabezal de troquel de diseño especial Full Shine. Esta combinación une diferentes materiales, como la combinación de la capa exterior de alto brillo y la capa de barrera mediante una capa adhesiva entre ellos con el fin de lograr el resultado perfecto. & Nbsp;
• La aplicación de coextrusión es la tecnología avanzada de la marca líder: Full Shine.

  • Curved arms for strong mold clamping, equipped with linear slide guideway, made in Germany for swift movement.
  • Screw drive in the control of direct-mounted gear box and inverter motor as power saving feature.
    ■ Die head unit with head-lifted device for cutting melted material swiftly and for easy alignment adjustment.
  • HMI touch screen (10.4”) from Japan, Fuji, Incorporating with PLC System for Easy Maintenance.
    ■ Blowing unit driven by hydraulic motor for changing mold easily-- innovative design.
    ■ Blowing unit, capable of equipping pre-lift feature to form small bottle neck.
  • Equipped with auto cutting device, conveyor, parison wall thickness controller as option.
    ■ High-efficient plasticizing extrusion screw for processing materials completely.
    ■ Full shine special-designed brake system for the carriage to provide stable movement and swift positioning.
    ■ Close-loop system with servo motor and servo circuit for mold carriage movement, as option.
EXPOSITION OF FULL SHINE'S MACHINE MODEL
  SCREW DIAMETER(M/M) MACHINE SERIES MOLD HEAD(DIE HEAD) MOLD STATION PRODUCT TYPE
FS- 40 (H) Horizontal (S) Single Mold Head (S) Single Mold Station (O) Original
45 (P) Parallel (D) Double Mold Heads (D) Double Mold Stations (C) Two Colors
55 (O) Standard / Oblique (T) Three Mold Heads   (D) Two Layers
65 (A) Pneumatic (F) Four Mold Heads   (T) Three Layers
75 (L) Frontal (E) Eight Mold Heads   (F) Four Layers
80 (I) Lateral     (L) Six Layers
90       (V) View Stripe
100       (P) PC baby bottle
Example
FS- 65 P D S D



Model FS-40 PSSD FS-45 PSSD FS-55 PSSD FS-65 PSSD FS-75 PSSD FS-55 PSSC FS-65 PSSC FS-75 PSSC
Style Double/single die head/single die holder Double color/single head single mold frame
1 Use plastic   PE PE PE PE PE PE PE PE
2 Screw diameter m/m 40/25 45/25 55/25 65/25 75/25 55/55 65/65 75/75
3 Screw ratio L/D 24/1 24/1 24/1 24/1 24/1 24/1 24/1 24/1
4 Screw speed r.p.m. 20-66 15-61 15-60 15-60 15-58 15-60 15-60 15-58
5 Inverter motor HP 5/2 7.5/2 10/2 15/2 25/2 10/10 15/15 25/25
6 Pump drive horsepower HP 5 7.5 10 10 15 10 10 15
7 Air compressor with horsepower HP 5 5 7.5 7.5 10 7.5 7.5 10
8 air pressure Kg/cm2 4-6 4-6 5-7 5-7 5-7 5-7 5-7 5-7
9 Clamping pressure Ton 2.8 3.9 4.4 6.9 10 4.4 6.9 10
10 Fuel tank capacity Gallon 38 55 60 80 120 60 80 120
11 Heating points ZONE 6 6 6 7 7 6 6 7
12 Heating capacity KW 9.5 12 15 19.5 22 19 24.5 26
13 Total power KW 19 25 32 40.5 44 43 56 77
14 Extrusion amount Kg/hr 15 24 42 55 75 42 55 75
15 Empty cycle per hour time/hr 1285 1030 880 720 650 880 720 600
16 Product capacity c.c./L 15-500 60-1000 150-2500 1L-5L 1L-10L 150-2500 1L-5L 1L-10L
17 product weight g. 5-40 10-100 20-170 40-280 80-500 20-170 40-280 80-500
18 Maximum and minimum product diameter m/m 10-75 20-100 30-140 50-200 80-260 30-140 50-200 80-260
19 Die mouth diameter m/m 50 56 80 150 200 80 150 200
20 Mold center distance m/m * * * * * * * *
21 Open and close mold limit m/m 50-320 50-410 140-540 160-670 50-410 140-540 160-670 160-670
22 Die length m/m 146-266 155-290 160-380 223-426 155-290 160-380 223-426 240-460
23 Die width m/m 300 320 360 430 320 360 430 430
24 Machine net weight Kg 3300 3800 4700 7600 3800 4700 7600 7300
25 Machine size m 2.6*1.85*2.7 3*1.9*2.8 3.1*2*2.8 3.6*1.6*3.1 4.2*1.7*3.2 3.1*2*2.8 3.6*1.6*3.1 4.2*1.7*3.2
