- Quick Die ajusta el diseño
- Retire la dirección de diseño de ajuste rápido
- Jig fabricación de moldes
- Sistema de control portátil (CD-EIII)
- SPI, Euromap 12, 67 estándar de interfaz
MODEL |
UX-30 |
UX-60 |
UX-150 |
ITEM |
UX-30/UXF-30 |
UX-60/UXF-60 |
U-150/UXF-150/UXF-150G |
Molding Machine Size (ton) |
10-30 |
50-90 |
80-150 |
A. Full Length |
480 |
||
B. Full Width |
540 |
620 |
740 |
C. Height of Main Arm |
1150 |
1250 |
1350 |
D. Height of Sub Arm |
X |
X/1350 |
|
E. Max. Radius of Products Handled |
292/357 |
292/357 |
342/407/407(342) |
F. Min. Distance b/w the Arms |
X |
X/60 |
|
G. Standby Position of Main Arm |
0-235/0-170 |
0-235/0-170 |
0-185/0-120/0-120 |
H. Standby Position of Sub Arm |
X |
0-185 |
|
I. Distance b/w Main arm and Base |
X |
||
J. Distance b/w Sub Arm and Base |
X |
||
K. Vertical Stroke of Main Arm |
350 |
450 |
550 |
L. Vertical Stroke of Sub Arm |
X |
X/X/550 |
|
M. Min. Distance from Sub Arm to Base |
X |
X/X/60 |
|
N. Min. Distance from Main Arm to Base |
62 |
60/60/150 |
|
P. Max. Demolding Stroke |
190 |
270 |
390 |
Q. Controller Width |
250 |
||
R. Controller Height |
935 |
||
S. X Axis Width |
232 |
||
T. Y Axis Width |
900 |
||
U. Z Axis Height |
500 |
||
V. Base Width |
125 |
