MÁQUINA DE PELÍCULA SOPLADA MONO-CAPA DE ALTA VELOCIDAD DE DOS CABEZAS

Clasificación: MÁQUINA DE PELÍCULA SOPLADA

ATLAS DEVELOPMENT MACHINERY CO., LTD.

País: Taiwán

Teléfono: 886-6-2027859

Fax: 886-6-203 2789

Persona de contacto: Mr.Kuo

Consulta Ahora

This two-head blown film machine line can produce 2 film rolls of the same width at the same time, and the production capacity is thus comparatively higher than models with only one die head. Thanks to the twin-head design, it not only occupies less space but also consumes less energy, which offers an economical solution for producing plastic bags of smaller width.

MODEL	ST55-500TD	ST55-600TD	ST65-650TD
Applicable Material	HDPE / MDPE / LDPE / LLDPE / EVA / CACO3 / Recycled Material
Screw Dia. (mm)	Φ55	Φ55	Φ65
Max. Film Width (mm)	400 mm/400 mm	500 mm/500 mm	600 mm/600 mm
Max. Output	80 kg/hr	100 kg/hr	160 kg/hr
Screw L/D Ratio	30:01:00	30:01:00	30:01:00
Main Motor (w/ Inverter)	40 HP	40 HP	60 HP
